Multi-Blade Hydraulic Stone Cutter SEMTECH - 2200/G14
This machine adopts microcomputer control system and easy-operating human-machine interface, uses imported inverter to control left-right feeding, adjusts the speed according to the stone material. It uses four pillars hydraulic lifting system , combination of chrome-plated guide pin and wear guide bush, with small gap , wearable, heavy structure , and guide sleeve with multi-layer seals , with waterproof , dust-proof , anti-spill , improving the service life, main motor uses Siemens motor, reduces the later using cost; forward-backward automatic slicing uses high-precision screw nut driving.
Technical Specification
Model | Maximum Diameter Of Blade (MM) | Number Of Blades | Lifting Travel (MM) | Max Cutting Size (MM) | Power Of Main Motor (KW) | Water Consumption (M3 / H) | Gross Weight (Tons) |
---|---|---|---|---|---|---|---|
Semtech - 2200/G14 | 2200 | 14 | 1200 | 4000 X 1550 X 900 | 45 X 55 | 26 | 16 |
