E.O.T Crane
Product Description:- EOT crane stands for electric overhead traveling crane. This is the most commonly used crane for lifting and shifting heavy loads. These cranes are electrically powered and operated by a control pendant, radio/IR remote pendant, or an operator cabin attached to the crane itself
Concept of EOT Crane:- EOT stands for Electric Overhead Travelling, which works as an overhead crane. Also called bridge cranes, these EOT cranes include parallel runways, in which a traveling bridge spans a gap. The manufacturer mounts the hoist on the bridge.
Technical Specification
| Capacity (in tons) | Span Of Bean (Mtrs.) | Lifting Height (Mtrs.) | Hook Center to Rail (Both Side) | Long Travel | Cross Travel | Lift | Long Travel (HP* x 2) | Cross Travel (HP) | Lift HP | Total Installed Power (HP*) |
| 5 | 8 - 40 | 6.50 | 950 | 14/20 | 16/20 | 2.2 / 2.7 | 1.5 | 1.5 | 5 | 9.5 |
| 10 | 8 - 40 | 6.50 | 1050 | 12/20 | 14/20 | 2.2 / 2.7 | 1.5 | 2 | 10 | 15.0 |
| 15 | 8 - 40 | 6.50 | 1050 | 10/20 | 10/20 | 2.2 / 2.7 | 1.5 | 2 | 10 | 21.0 |
| 20 | 8 - 40 | 6.50 | 1100 | 10/20 | 10/20 | 2.2 / 2.7 | 2 | 2 | 20 | 26.0 |
| 30 | 8 - 30 | 6.50 | 1200 | 10/20 | 10/20 | 2.2/2.5 | 3 | 2 | 25 | 40 |
